HUSQVARNA 565
or
Call (914) 738-4400
Specifications
| Manufacturer | Husqvarna |
| Condition | New |
| Output shaft power1 | 5 hp |
| Cylinder displacement | 70.6 cm³ |
| Torque, max. | 4.2 Nm |
| Torque, max. at rpm | 6,900 rpm |
| Chain speed at max power | 67.9 fts |
| Clutch engagement speed (±120) | 3,800 rpm |
| Electrode gap | 0.02 in |
| Idling speed | 2,700 rpm |
| Ignition module air gap | 0.01 in |
| Maximum power speed | 9,300 rpm |
| Oil pump type | Adjustable flow, no flow at idle |
| Spark Plug | NGK BPMR7A |
| Recommended bar length, min | 15 in |
| Pitch | 3/8" |
| Recommended bar length, max | 28 in |
| Chain type | C83 |
| Bar length (inch) | 20 in |
| Sprocket type | Rim 7 |
| Gauge | .050" |
| Weight (excl. cutting equipment) | 14.3 lbs |
| Sound pressure level at operators ear | 105 dB(A) |
| Sound power level, guaranteed (LWA) | 119 dB(A) |
| Sound power level, measured | 117 dB(A) |
| Equivalent vibration level (ahv, eq) rear handle | 5.3 m/s² |
| Equivalent vibration level (ahv, eq) front handle | 5.2 m/s² |
| Oil tank volume | 0.7 US pint |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| Exhaust emissions (CO₂ EU V)2 | 804 g/kWh |
