Dust removal system ID 130/22 Z22

ID 130/22 Z22 industrial deduster suitable for use in Zone 22. Designed for vacuuming fine shavings and hazardous dusts (OEL > 0.1 mg/m³) with a container volume of 170 litres. Mobile, three-phase powered, and constructed with a steel housing for industrial demands.

Designed for vacuuming large quantities of fine shavings and hazardous dusts (OEL > 0.1 mg/m³) as well as for use in Zone 22 potentially explosive atmospheres, the ID 130/22 Z22 mobile industrial deduster proves its worth in demanding industrial applications. Its IE3 efficiency class radial compressor with an air flow rate of 1.329 m³/h also enables continuous operation in a three-shift system. The three-phase, mobile dust collector with a rated input power of 2.2 kW features a dust class M filter system, integrated mechanical filter shaking, and a 170-litre waste container. Thanks to the drop-down chassis, the container can be emptied without removing the drive head. A PE bag with an integrated closure mechanism and pressure compensation hose on the dust collector supports dust-reduced emptying and disposal of the vacuumed material.

Features and benefits

Features extra-large star filter and additional cartridge filter

Longer service life, less maintenance effort and lower costs.

Very effective filter cleaning thanks to reinforcing mesh in the filter bags.

Simple and safe emptying without removal of drive head

Set-down trolley and rolling container for ergonomic emptying.

Designed for dust class M for high occupational safety

Dust class M filter engineering for vacuuming hazardous dust (OEL > 0.1 mg/m³).

DGUV certificate H3 for wood dust

H3 certificate applies when using the machine with DN 120.

Reliable disposal of dust in a PE bag.

Equipment

Accessories included in the scope of delivery: no
