Industrial vacuums IVM 40/12-1 H Z22
Specifications
| Manufacturer | Kaercher |
| Condition | New |
| Voltage (V) | 220 - 240 |
| Frequency (Hz) | 50 - 60 |
| Air flow (l/s/m³/h) | 43,8 / 158 |
| Vacuum (mbar/kPa) | 249 / 24,9 |
| Container capacity (l) | 40 |
| Container material | Stainless steel |
| Rated input power (kW) | 1 x 1,2 |
| Vacuuming type | Electric |
| Connection nominal diameter | DN 70 |
| Accessory nominal diameter | DN 40 |
| Sound pressure level (dB(A)) | 73 |
| Cable length (m) | 10 |
| Main filter dust class | M |
| Filter area for main filter (m²) | 1,6 |
| Secondary filter dust class | H |
| Filter area for secondary filter (m²) | 1,6 |
| Weight without accessories (kg) | 51 |
| Weight incl. packaging (kg) | 51 |
| Dimensions (L × W × H) (mm) | 645 x 655 x 1140 |
Description
Mobile middle class industrial vacuum cleaner with EC turbine. Suitable for the safe vacuuming of fine and coarse solids in dust class H and for use in ATEX zone 22.
For universal vacuuming of fine and coarse solids in ATEX zone 22: the single-motor, explosion-protected mid-class industrial vacuum cleaner IVM 40/12-1 H Z22 equipped with an EC turbine. The device operates in single-phase operation, has a compact design, is mobile, and is built for applications where special safety regulations must be observed. The large dust class M star filter can be cleaned during operation using the Pull and Clean filter cleaning system. In addition, the vacuum cleaner is equipped with a downstream certified H cartridge filter with filter detection and is certified to dust class H. The filter container and collection container are made of acid-resistant stainless steel, while the chassis is made of steel.
Features and benefits
Certified for ATEX Zone 22
Explosion-proof industrial vacuum for safe vacuuming in ATEX Zone 22.Dust class H
Overall device certified according to DIN EN 60335-2-69 for dust class H.For safely picking up solids and dusts up to dust class H.Low-wear EC turbine
Brushless design for low-wear operation.Suitable for three-shift operation thanks to a minimum service life of 5000 hours.Manual pull-and-clean filter cleaning
Features extra-large star filter and additional cartridge filter
Equipment
