Dust removal system ID 130/22 Afc

Compact, mobile dust extractor ID 130/22 Afc with motorised filter shaking for vacuuming large quantities of fine swarf and hazardous dusts (OEL ≥ 0.1 mg/m³). Torque-operated.

The three-phase powered and mobile industrial dust collector ID 130/22 Afc with a 2.2 kW power input and a dust class M filter system is designed for vacuuming fine shavings and hazardous dusts (OEL ≥ 0.1 mg/m³). Compact filter cleaning is carried out by an electric shaking mechanism for constant suction power. The dust collector features a radial compressor (efficiency class IE3) designed for continuous three-shift operation with a volume flow of 1,329 m³/h. With its steel casing and tool-free filter access, it meets central requirements for industrial applications. A drop-down chassis enables ergonomic emptying of the 170-litre collection container without removing the drive head. Thanks to a PE bag with an integrated closure mechanism and a pressure compensation hose on the device, emptying the vacuumed dust is carried out safely and with low dust emissions.

Features and benefits

Designed for dust class M for high occupational safety

Dust class M filter engineering for vacuuming hazardous dust (OEL > 0.1 mg/m³).

Simple and safe emptying without removal of drive head

Set-down trolley and rolling container for ergonomic emptying.

Low-dust emptying system for hazardous dusts of dust class M (OEL > 0.1 mg/m³)

Dust-free emptying thanks to PE sack with integrated closing mechanism.Reliable disposal of dust in a PE bag.
