Industrial vacuums IVR 60/30 Sc M ACD
Specifications
| Manufacturer | Kaercher |
| Condition | New |
| Number of current phases (Ph) | 3 |
| Voltage (V) | 400 |
| Frequency (Hz) | 50 - 60 |
| Air flow (l/s/m³/h) | 88 / 312 |
| Vacuum (mbar/kPa) | 260 / 26 |
| Container capacity (l) | 60 |
| Container material | Steel |
| Rated input power (kW) | 3 |
| Vacuuming type | Electric |
| Connection nominal diameter | DN 70 |
| Accessory nominal diameter | DN 50 |
| Sound pressure level (dB(A)) | 62 |
| Cable length (m) | 7,5 |
| Main filter dust class | M |
| Filter area for main filter (m²) | 1,75 |
| Colour | anthracite |
| Weight without accessories (kg) | 139 |
| Weight incl. packaging (kg) | 139 |
| Dimensions (L × W × H) (mm) | 855 x 760 x 1675 |
Description
IVR 60/30 Sc M ACD industrial vacuum cleaner, suitable for continuous operation in non-explosive areas. For safe vacuuming of combustible and hazardous types of dust (OEL ≥ 0.1 mg/m³) and solid.
Industrial vacuum cleaner IVR 60/30 Sc M ACD designed for mobile and stationary use in non-explosive areas, featuring dust class M filter technology for the safe vacuuming of small quantities of fine shavings as well as combustible and hazardous dusts (OEL ≥ 0.1 mg/m³). With a rated input power of 3 kW, the machine is equipped with a three-phase motor and an efficiency class IE2 side channel blower, designed for continuous three-shift operation. An ergonomic set-down chassis enables emptying of the 60-litre collection container without removing the drive head. The low-dust emptying system is complemented by a PE bag with integrated closing mechanism and pressure compensation hose that ensures safe disposal of the vacuumed material. The three-phase powered vacuum cleaner features a washable dust class M pocket filter. Thanks to manual filter cleaning via a shaking lever, constant suction power is maintained. The sound-dampened drive unit ensures reduced-noise operation at 62 dB(A).
Features and benefits
ACD – Applied for Combustible Dust
For the safe and economical vacuuming of combustible dusts.Conforms to the IEC 60335-2-69 standard.Designed for high mechanical stress and versatile in use.
With practical, movable suction hose port/pipe bend.Despite its very compact design, it features numerous options for carrying accessories.The device and chassis are designed for industrial use due to their wall thickness.Wear-resistant side channel blower
With 3 kW power and soft start-up for vacuuming small amounts of dust and solid materials.For strong suction power and service life of at least 20,000 hours.Optimally suited for mobile use in multiple shift operation.Convenient, manual filter cleaning
Equipped with large pocket filter
Equipment
