Industrial vacuums IVR 100/40 Sc H ACD
Specifications
| Manufacturer | Kaercher |
| Condition | New |
| Number of current phases (Ph) | 3 |
| Voltage (V) | 400 |
| Frequency (Hz) | 50 |
| Air flow (l/s/m³/h) | 138 / 495 |
| Vacuum (mbar/kPa) | 140 / 14 |
| Container capacity (l) | 100 |
| Container material | Steel |
| Rated input power (kW) | 4,7 |
| Vacuuming type | Electric |
| Connection nominal diameter | DN 70 |
| Accessory nominal diameter | DN 50 |
| Sound pressure level (dB(A)) | 71 |
| Cable length (m) | 7,5 |
| Main filter dust class | M |
| Filter area for main filter (m²) | 1,75 |
| Secondary filter dust class | H |
| Filter area for secondary filter (m²) | 3 |
| Colour | anthracite |
| Weight without accessories (kg) | 205 |
| Weight incl. packaging (kg) | 205,9 |
| Dimensions (L × W × H) (mm) | 855 x 760 x 2380 |
Description
The IVR 100/40 Sc H ACD combines a 100-litre container capacity with a compact footprint. Suitable for vacuuming combustible dusts for installation in non-explosive areas.
Industrial vacuum cleaner IVR 100/40 Sc H ACD for installation in non-explosive areas. Despite the 100-litre container capacity, the machine requires a compact footprint and is suitable for use in production halls with confined spaces. An internally reinforced pocket filter (dust class M) with a filter area of 1.75 m², a dust class H cartridge filter with a filter area of 3 m², and a cyclone-like pre-separation system enable the intake of fine and combustible dusts. A pressure compensation hose and hold-down device ensure low-dust vacuuming directly into a waste disposal bag. The collection container is connected to the vacuum cleaner via a set-down mechanism that can be operated in an upright position. An integrated silencer reduces operating noise to 71 dB(A). The construction and the side channel blower are designed for continuous industrial use.
Features and benefits
ACD – Applied for Combustible Dust
For the safe and economical vacuuming of combustible dusts.Conforms to the IEC 60335-2-69 standard.Designed for high mechanical stress and versatile in use.
With practical, movable suction hose port/pipe bend.With numerous options for accessory storage.The device and chassis are designed for industrial use due to their wall thickness.Wear-resistant side channel blower
With 4 kW power and soft start for vacuuming large quantities of dust and solids.For strong suction power and service life of at least 20,000 hours.Optimally suited for mobile use in multiple shift operation.Convenient, manual filter cleaning
Equipped with large pocket filter
Equipment
