Industrial vacuums IVR 60/24-2 Sc H ACD

For safe vacuuming of combustible and hazardous dusts (OEL < 0.1 mg/m³) and solids: the mobile industrial vacuum cleaner IVR 60/24-2 Sc H ACD for operation in non-explosive areas.

For installation in non-explosive areas: The safe vacuuming of combustible and hazardous dusts (OEL < 0.1 mg/m³) as well as solids is the main purpose of the IVR 60/24-2 Sc H ACD industrial vacuum cleaner with a rated input power of 2.4 kW. Operated with alternating current and equipped with dust class H filter technology, the mobile industrial vacuum cleaner features a washable dust class M pocket filter with welded seams, a dust class H cartridge filter, and effective manual filter cleaning. This ensures that the suction power on two bypass turbines remains constant at all times. With a 60-litre collection container capacity, the machine is designed for small to medium quantities. A safety filter bag with integrated closing mechanism and pressure compensation hose ensures low-dust emptying and safe disposal of the vacuumed material, while an ergonomic set-down chassis makes removing the drive head unnecessary. The sound-dampened drive unit ensures reduced-noise operation at 68 dB(A), while the chassis provides high mobility on site.

Features and benefits

ACD – Applied for Combustible Dust

For the safe and economical vacuuming of combustible dusts.Conforms to the IEC 60335-2-69 standard.

Designed for high mechanical stress and versatile in use.

With practical, movable suction hose port/pipe bend.Despite its very compact design, it features numerous options for carrying accessories.The device and chassis are designed for industrial use due to their wall thickness.

Fitted with two very quiet fan motors

For powerful suction power and optimum cleaning performance.Fans can be switched on separately for individual suction power as required.The drive head with a sound pressure level of 68 dB(A) ensures an even discharge of the cooling air.

Convenient, manual filter cleaning

Effortless operation by means of an ergonomically placed lever if required.

Extends the life of the filter and thus reduces the maintenance effort.

Identical cleaning results, regardless of the amount of force used.

Equipped with large pocket filter

For safely picking up solids and dusts up to dust class H.

Also suitable for large quantities of dust.

Special geometry of the filter prevents suctioned solids getting caught.

Equipment

Main filter: Pocket filter

Secondary filter: Cartridge filter

Accessories included in the scope of delivery: no
