Industrial vacuums IVR-L 200/24-2 Tc Dp

or
Call (914) 738-4400

Specifications

ManufacturerKaercher
ConditionNew
Number of current phases (Ph)1
Voltage (V)220 - 240
Frequency (Hz)50 - 60
Air flow (l/s/m³/h)148 / 532
Vacuum (mbar/kPa)230 / 23
Container capacity (l)200
Rated input power (kW)2,4
Vacuuming typeElectric
Connection nominal diameterDN 50
Accessory nominal diameterDN 50
Main filter dust classL
Filter area for main filter (m²)0,45
Sound pressure level (dB(A))69
Cable length (m)10
Weight without accessories (kg)131
Weight (with accessories) (kg)131
Weight incl. packaging (kg)131,9
Dimensions (L × W × H) (mm)1485 x 760 x 1550

Description

AC-powered liquid and swarf vacuum cleaner IVR-L 200/24-2 Tc Dp for vacuuming oils and swarf. Design made of 1.25 mm thick steel.

The AC-powered liquid and swarf vacuum cleaner IVR-L 200/24-2 Tc Dp, featuring a two-turbine solution and 2.4 kW input power, is designed for vacuuming large quantities of oils, cooling emulsions, and swarf. The washable pocket filter with welded seams is designed to be washable and maintains the suction power, while an optional sieve basket separates liquid and solid vacuumed media. The emptying system with a tilting chassis allows for tilt emptying via a roll-off mechanism. The use of a forklift is also possible. Liquids from the 200-litre collection container are drained via the drain hose with a fill level indicator or the integrated, infinitely variable barrel pump. A sound pressure level of 69 dB(A) is achieved by a sound-insulated drive unit and an exhaust silencer.

Features and benefits

Ergonomic tilting chassis

Sophisticated system for safe, manual, effortless emptying.Chassis system enables ergonomic tilted emptying using the roll-off mechanism.Quick and convenient emptying of the large 200-litre containers by tilting.

Drum pump function

An autonomous barrel pump significantly increases the ability for vacuumed matter to be returned.Transparent hose for checking the amount of fluid absorbed.

High robustness, flexibility and modularity

The device and chassis are designed for industrial use due to their wall thickness.Rotatable hose connection with up to 360° rotatable pipe bend.Optionally available with overfill protection, strainer or accessories holder.

Fitted with two very quiet fan motors

  • For powerful suction power and optimum cleaning performance.
  • Fans can be switched on separately for individual suction power as required.
  • The drive head with a sound pressure level of 68 dB(A) ensures an even discharge of the cooling air.

    • Equipped with compact surface filter of dust class L

  • Reliably prevents coarse particles from entering the suction turbines.

    • Equipment

  • Main filter: Surface filter
  • Drum pump function
    • Show All
