High-pressure cleaner HD 10/16-4 Cage Ex
Specifications
| Manufacturer | Kaercher |
| Condition | New |
| Number of current phases (Ph) | 3 |
| Voltage (V) | 400 |
| Frequency (Hz) | 50 |
| Flow rate (l/h) | 1000 |
| Inlet temperature (°C) | 50 |
| Working pressure (bar/MPa) | 160 / 16 |
| Max. pressure (bar/MPa) | 220 / 22 |
| Connected load (kW) | 5,5 |
| Colour | anthracite |
| Weight (with accessories) (kg) | 122,6 |
| Weight incl. packaging (kg) | 131,2 |
| Dimensions (L × W × H) (mm) | 980 x 720 x 1100 |
Description
The explosion-proof HD 10/16-4 Cage Ex high-pressure cleaner was developed specially for use in ATEX zones. Working pressure 160 bar, corresponding to a water flow of 1,000 litres per hour.
Potentially explosive areas, "ATEX zones", place particular demands on components and materials. Our HD 10/16-4 Cage Ex high-pressure cleaner meets these requirements and complies with all of the stringent safety regulations in its explosion-proof design. With a working pressure of 160 bar and water flow rate of around 1,000 litres per hour, the machine is designed for a variety of cleaning tasks. Moreover, it incorporates outstanding technical innovations that make cleaning effortless and take handling to a new level: the EASY!Force high-pressure gun and EASY!Lock quick-release fasteners. While the EASY!Force high-pressure gun makes use of the recoil force of the high-pressure jet to reduce the holding force to zero, the EASY!Lock quick-release fasteners enable handling that is five times faster than with conventional screw connections, without losing any robustness or longevity. The HD 10/16-4 Cage Ex combines maximum safety with outstanding cleaning performance and durable technology.
Features and benefits
Powder-coated cage frame, electrically conductive
Robust tubular steel frame.With integrated crane hook.Protection against damage to the machine.Explosion-proof equipment
Conductive rubber tyres.Designed for commercial and industrial operation.
Four-pole, low-speed air-cooled electric motor.Brass cylinder head and ceramic pistons.Crankshaft pump with ceramic pistons.Operational safety
