High-pressure cleaner HD 6/15 M St

The compact HD 6/15 M St motor/pump unit for stationary use, with AC motor, wall mount, 600 litres per hour flow rate and automatic pressure relief.

The motor/pump unit HD 6/15 M St with AC motor features a 3-piston axial pump with stainless steel pistons. The device generates a working pressure of 150 bar. A fine water filter and automatic pressure relief are built in to protect the pump and the high-pressure components. The device structure allows access to the components. For vertical mounting on walls or as a horizontal built-in device, there is a 3-point mount on the back of the device.

Features and benefits

High-quality equipment

Automatic pressure relief for protecting the components extends their life.Powerful, 2-pole, air-cooled electric motor.High-quality brass cylinder head

Flexible operation

For vertical and horizontal operation.

Prepared for stationary operation

Simple and solid 3-point attachment for wall mounting on the rear of unit.Space-saving, compact design.Integrated storage possibilities reduce the set-up times.

Easy servicing

Easy access to the cylinder head through the open part at the bottom of the machine.

Quick access to the electrical box by simple removal of the machine cover.

Large, easy-to-reach water fine filter for protecting the pump against dirt particles in the water.

Increased energy efficiency

Newly developed 3-piston axial pump for considerably reduced flow and pressure losses.

20% increase in cleaning performance and energy efficiency.

Equipment

Pressure cut-off
