High-pressure cleaner HD 7/14-4 M

or
Call (914) 738-4400

Specifications

ManufacturerKaercher
ConditionNew
Number of current phases (Ph)1
Voltage (V)230
Frequency (Hz)50
Flow rate (l/h)700
Inlet temperature (°C)60
Working pressure (bar/MPa)140 / 14
Max. pressure (bar/MPa)210 / 21
Connected load (kW)3,4
Power cable (m)5
Water inlet3/4″
ColourAnthracite
Weight (with accessories) (kg)37
Weight incl. packaging (kg)40,4
Dimensions (L × W × H) (mm)400 x 455 x 700

Description

AC-powered, mobile high-pressure cleaner HD 7/14-4 M with 3-piston axial pump. Compact device for deployment.

The unheated high-pressure cleaner HD 7/14-4 M features automatic pressure relief for stand-by operation. The device is equipped with the EASY!Force high-pressure gun and EASY!Lock quick-release fasteners. It is designed for vertical and horizontal operation. Further equipment includes a 3-piston axial pump with a brass cylinder head as well as options for placing and storing accessories. The device structure allows access to maintenance-relevant components.

Features and benefits

High-quality equipment

Automatic pressure relief for protecting the components extends their life.Powerful, 4-pole, slow-running electric motor.High-quality brass cylinder head

Flexible operation

For vertical and horizontal operation.Maximum stability during horizontal operation as the wheels do not touch the floor.

Outstanding mobility

The push handle, which can be retracted at the touch of a button, increases the compactness of the machine and reduces the spatial requirement.Can be easily stored in service vehicles.Integrated storage possibilities reduce the set-up times.

Clever accessory storage

  • Holder for the cup foam lance.
  • EASY!Lock TR20 permits storage of the Power nozzle or a surface cleaner directly at the machine.
  • Practical nozzle compartment for storing the rotary nozzle.

    • Easy servicing

  • Easy access to the cylinder head through the open part at the bottom of the machine.
  • Quick access to the electrical box by simple removal of the machine cover.
  • Large, easy-to-reach water fine filter for protecting the pump against dirt particles in the water.

    • Effortless and time-saving solutions

  • Fatigue-free EASY!Force high-pressure gun.
  • Robust EASY!Lock quick-release couplings: five times faster than screws.

    • Increased energy efficiency

  • Newly developed 3-piston axial pump for considerably reduced flow and pressure losses.
  • 20% increase in cleaning performance and energy efficiency.

    • Scope of supply

  • Spray gun: EASY!Force
  • Spray lance: 840 mm
  • Power nozzle

    • Equipment

  • High-pressure hose length: 10 m
  • High-pressure hose type: Premium quality
  • Pressure cut-off
    • Show All
