High-pressure cleaner HD 8/18-4 M St

Mid-class pump unit HD 8/18-4 M St with 3-piston axial pump with brass cylinder head and 4-pole, slow-running three-phase motor. Can be used horizontally and vertically.

The motor/pump unit HD 8/18-4 M St comprises a 3-piston axial pump with a brass cylinder head, a 4-pole three-phase motor and pressure switch control. The device is designed for vertical and horizontal operation. A 3-point mount on the back of the device enables vertical wall mounting or horizontal installation. The high-pressure pump and electronic components are accessible; a water filter is installed. The Servo-Control function enables the adjustment of water volume and working pressure. Automatic pressure relief protects the high-pressure components in stand-by operation.

Features and benefits

High-quality equipment

Automatic pressure relief for protecting the components extends their life.Powerful, 4-pole, slow-running electric motor.High-quality brass cylinder head

Flexible operation

For vertical and horizontal operation.

Prepared for stationary operation

Simple and solid 3-point attachment for wall mounting on the rear of unit.Space-saving, compact design.Robust plastic chassis reliably protects the pump against damage and dirt.

Easy servicing

Easy access to the cylinder head through the open part at the bottom of the machine.

Quick access to the electrical box by simple removal of the machine cover.

Large, easy-to-reach water fine filter for protecting the pump against dirt particles in the water.

Increased energy efficiency

Newly developed 3-piston axial pump for considerably reduced flow and pressure losses.

20% increase in cleaning performance and energy efficiency.

Scope of supply

Servo Control

Equipment

Pressure cut-off
