High-pressure cleaner HD 7/14-4 M Cage
Specifications
| Manufacturer | Kaercher |
| Condition | New |
| Number of current phases (Ph) | 1 |
| Voltage (V) | 230 |
| Frequency (Hz) | 50 |
| Flow rate (l/h) | 700 |
| Inlet temperature (°C) | 60 |
| Working pressure (bar/MPa) | 140 / 14 |
| Max. pressure (bar/MPa) | 210 / 21 |
| Connected load (kW) | 3,1 |
| Power cable (m) | 5 |
| Water inlet | 3/4″ |
| Colour | anthracite |
| Weight (with accessories) (kg) | 42 |
| Weight incl. packaging (kg) | 46,3 |
| Dimensions (L × W × H) (mm) | 420 x 460 x 970 |
Description
HD 7/14-4 M Cage: unheated high-pressure cleaner with 4-pole, slow-running AC motor, robust tubular steel frame, automatic pressure relief and 140 bar working pressure.
The EASY!Force high-pressure gun, along with the EASY!Lock quick-release couplings, on our HD 7/14-4 M Cage high-pressure cleaner ensure you can work without tiring and save on set-up and dismantling time. The EASY!Force high-pressure gun utilises the recoil force of the high-pressure jet to reduce the retaining force to zero, while the EASY!Lock quick-release couplings enable handling that is five times faster than conventional screw connections, without compromising on robustness or longevity. A powder-coated tubular steel frame reliably protects the machine from external damage under tough working conditions and during transportation. Internally, the automatic pressure relief feature protects the high-pressure components. Driven by a 4-pole, slow-running AC motor, the newly developed 3-piston axial pump with brass cylinder head enables an increase in the cleaning performance and energy efficiency of the HD 7/14-4 M Cage of around 20%. The high-pressure cleaner is also designed for vertical and horizontal operation, and boasts easy accessibility to the maintenance-relevant components.
Features and benefits
Designed for continuous operation in commercial and industrial use.
Sturdy tubular steel frame protects all components.The tubular steel frame is also suitable for simple fastening and lashing of the machine in the service vehicle.Robust plastic chassis reliably protects the pump against damage and dirt.High-quality equipment
Automatic pressure relief for protecting the components extends their life.Powerful, 4-pole, slow-running electric motor.High-quality brass cylinder headEasy servicing
Easy access to the cylinder head through the open part at the bottom of the machine.Quick access to the electrical box by simple removal of the machine cover.Large, easy-to-reach water fine filter for protecting the pump against dirt particles in the water.Increased energy efficiency
Effortless and time-saving solutions
Flexible operation
Clever accessory storage
Scope of supply
Equipment
