High-pressure cleaner HD 7/16-4 MXA Kfz

or
Call (914) 738-4400

Specifications

ManufacturerKaercher
ConditionNew
Number of current phases (Ph)3
Voltage (V)400
Frequency (Hz)50
Flow rate (l/h)350 - 700
Inlet temperature (°C)60
Working pressure (bar/MPa)30 - 160 / 3 - 16
Max. pressure (bar/MPa)240 / 24
Connected load (kW)4,2
Power cable (m)5
Water inlet3/4″
Colouranthracite
Weight (with accessories) (kg)46,1
Weight incl. packaging (kg)50
Dimensions (L × W × H) (mm)400 x 455 x 966

Description

The HD 7/16-4 MX offers an hourly water volume of 700 l at 160 bar working pressure and a hose reel.

The unheated high-pressure cleaner HD 7/16-4 MX features a 4-pole, slow-running three-phase motor and an integrated hose reel. It is equipped with a 3-piston axial pump with a brass cylinder head. An automatic pressure relief and a water filter are integrated. The device is provided with the EASY!Force high-pressure gun and EASY!Lock quick-release fasteners. Accessories such as the optional cup foam lance can be stored on the device.rs enable up to 5-times faster handling compared to conventional screw connections without any negative impacts on the robustness and durability. There is suitable space for accessories, including the optional cup foam lance, directly at the device thanks to clever solutions.

Features and benefits

Spring-mounted automatic hose reel

  • Maximum comfort when handling the high-pressure hose.
  • Makes possible short set-up times thanks to quick winding and unwinding.
  • Avoids tripping hazards, thus increasing operational safety.

    • Additional stand

  • Enlarges the stand area of the machine.
  • Increases the tilt stability when operated upright.

    • High-quality equipment

  • Automatic pressure relief for protecting the components extends their life.
  • Powerful, 4-pole, slow-running electric motor.
  • High-quality brass cylinder head

    • Clever accessory storage

  • Holder for the cup foam lance.
  • EASY!Lock TR20 permits storage of the Power nozzle or a surface cleaner directly at the machine.
  • Practical nozzle compartment for storing the rotary nozzle.

    • Outstanding mobility

  • The push handle, which can be retracted at the touch of a button, increases the compactness of the machine and reduces the spatial requirement.
  • Can be easily stored in service vehicles.
  • Integrated storage possibilities reduce the set-up times.

    • Flexible operation

  • For vertical and horizontal operation.
  • Maximum stability during horizontal operation as the wheels do not touch the floor.

    • Easy servicing

  • Easy access to the cylinder head through the open part at the bottom of the machine.
  • Quick access to the electrical box by simple removal of the machine cover.
  • Large, easy-to-reach water fine filter for protecting the pump against dirt particles in the water.

    • Effortless and time-saving solutions

  • Fatigue-free EASY!Force high-pressure gun.
  • Robust EASY!Lock quick-release couplings: five times faster than screws.

    • Increased energy efficiency

  • Newly developed 3-piston axial pump for considerably reduced flow and pressure losses.
  • 20% increase in cleaning performance and energy efficiency.

    • Scope of supply

  • Spray gun: EASY!Force
  • Spray lance: 600 mm
  • Power nozzle
  • Servo Control
  • Quick coupling
  • Foam lance

    • Equipment

  • High-pressure hose length: 15 m
  • High-pressure hose type: Flex
  • ANTI!Twist
  • Pressure cut-off
    • Show All
