Submersible dirty water pump SP 22.000 Dirt Level Sensor

or
Call (914) 738-4400

Specifications

ManufacturerKaercher
ConditionNew
Rated input power (W)750
Max. flow rate (l/h)< 22000
Delivery temperature (°C)max. 35
Delivery head (m)8
Pressure (bar)max. 0,8
Grain size (mm)max. 30
Immersion depth (m)max. 7
After-running time (s)15
Min. residual water, manual (mm)35
Residual water height (mm)35
Connection threadG1 1/2
Pressure-side connection threadG1/2 internal thread
Power cable (m)10
Voltage (V)230 - 240
Frequency (Hz)50
ColourYellow
Weight without accessories (kg)6,7
Weight incl. packaging (kg)7,7
Dimensions (L × W × H) (mm)238 x 293 x 354

Description

With level sensor and integrated prefilter: For challenging drainage tasks the submersible dirty water pump SP 22,000 Dirt Level Sensor manages to pump out dirty water at a rate of up to 22,000 l/h.

An individually adjustable level sensor starts the SP 22,000 Dirt Level Sensor dirty water pump upon contact with water. If the water level drops below the sensor, the pump stops automatically after 15 seconds. This submersible pump handles up to 22,000 l/h of dirty water containing particles up to 30 mm in size, making it suitable for garden ponds, flooded basements, or construction pits. An integrated, pull-down stainless steel prefilter protects against clogging when dealing with heavily soiled water. An automatic/manual switch allows the pump to be set to continuous operation. In both continuous and automatic modes, the pump can drain water down to a residual level of 35 mm, depending on the level sensor setting. The pump features a stainless steel housing and a slide ring sealing. The Quick Connect port allows for the connection of 1", 1 1/4", and 1 1/2" hoses. Registering via the Home & Garden app allows for a warranty extension to 5 years.

Features and benefits

Ceramic face seal.

For an extra long lifetime.

Level Sensor

For continuously variable definition of the switch-on and switch-off points of the pumps.

Quick Connect

Connection thread for quick and uncomplicated connection of 1", 1 1/4" and 1 1/2" hoses.

Designed for dirty water

  • Reliable pumping of water with dirt particles up to 30 mm in size.

    • Auto/manual switch

  • For switching between automatic and manual mode.

    • Comfortable carrying handle

  • Comfortable to hold and can also be used as a rope holder.

    • Robust and integrated stainless steel prefilter

  • Protects the pump against excessively heavy soiling and thus prevents the pump impeller from becoming blocked.

    • Scope of supply

  • Hose connection piece: 1″, 1 1/4″, 1 1/2″

    • Equipment

  • Comfortable carrying handle
  • Easy hose connection thanks to Quick Connect
  • Switching between manual/automatic operation: Switch on the pump
  • Level sensor: Continuous switching level definition
  • Integrated stainless steel pre-filter
  • In automatic operation (auto), the pump automatically switches with the water level
  • In manual operation, the pump runs continuously to ensure the minimum quantity of residual water
  • Ceramic face seal.
  • Stainless steel housing
    • Show All

    Documents
