Flat suction submersible pump SP 9.000 Flat

or
Call (914) 738-4400

Specifications

ManufacturerKaercher
ConditionNew
Rated input power (W)280
Max. flow rate (l/h)< 9000
Delivery temperature (°C)max. 35
Delivery head (m)6
Pressure (bar)max. 0,6
Flat pick-up to a depth of (mm)1
Grain size (mm)max. 5
Immersion depth (m)max. 7
Min. residual water, manual (mm)1
Residual water height (mm)1
Connection threadG1 1/2
Pressure-side connection threadG1/2 internal thread
Power cable (m)10
Voltage (V)230 - 240
Frequency (Hz)50
ColourYellow
Dimensions (L × W × H) (mm)227 x 240 x 262
Weight without accessories (kg)3,7
Weight incl. packaging (kg)4,5

Description

Manages up to 9,000 l/h and pumps down to a mop-dry 1 mm level: The flat-suction SP 9,000 Flat submersible pump is the compact entry-level pump for clear to slightly dirty water.

The flat-suction submersible pump SP 9.000 Flat pumps clear or slightly dirty water containing particles up to 5 mm in size. With a flow rate of up to 9,000 l/h, it is suitable for draining small pools or cellars flooded by groundwater ingress or washing machine leaks. A float switch turns the pump on and off based on the water level and protects against dry running. The float can be locked in position to allow for continuous operation. The SP 9.000 Flat features foldable feet; a higher flow rate is achieved when the feet are extended. With the feet retracted, the clear-water submersible pump starts at a water level of just 7 mm and can pump down to a residual water level of 1 mm (wiped-dry result) during continuous operation. Hoses with diameters of 1", 1 1/4", and 1 1/2" can be connected via the Quick Connect port. Registering via the Home & Garden app allows for a warranty extension to 5 years.

Features and benefits

Ceramic face seal.

For an extra long lifetime.

Float switch

Switches the pump on and off again according to the water level, preventing dry running.

Quick Connect

Connection thread for quickly and simply connecting 1″, 1 1/4″ and 1 1/2″ hoses or a G1 connection.

Foldable legs

  • Switching from normal operation with a higher capacity to 1 mm flat pick-up with a mop dry result.

    • Automatic venting

  • The pump starts working in manual mode from a water level of 7 mm.

    • Possibility of fixing the float switch

  • For switching to continuous operation.

    • Comfortable carrying handle

  • Comfortable to hold and can also be used as a rope holder.

    • Sturdy and easy to attach prefilter as accessory

  • Protects the pump against excessively heavy soiling and thus prevents the pump impeller from becoming blocked.

    • Scope of supply

  • Hose connection piece: G1, 1”, 1 1/4”, 1 1/2”

    • Equipment

  • Comfortable carrying handle
  • Easy hose connection thanks to Quick Connect
  • Switching between manual/automatic operation: Possibility of fixing the float switch
  • Switch to flat pick-up
  • Float switch
  • Ceramic face seal.
  • In manual operation, the pump runs continuously to ensure the minimum quantity of residual water
    • Show All
